Oxford Thermostatic Shower Set - 18" Shower Arm & Hand Shower - 1/2" IPS - Brushed Nickel

198345 SH198345
3.9 out of 5 Customer Rating

Product Images

Oxford Thermostatic Shower Set - 18" Shower Arm & Hand Shower - 1/2" IPS - Brushed Nickel, , large image number 0 Oxford Thermostatic Shower Set - 18" Shower Arm & Hand Shower - 1/2" IPS - Brushed Nickel, , large image number 1 Oxford Thermostatic Shower Set - 18" Shower Arm & Hand Shower - 1/2" IPS - Brushed Nickel, , large image number 2 Oxford Thermostatic Shower Set - 18" Shower Arm & Hand Shower - 1/2" IPS - Brushed Nickel, , large image number 3
Oxford Thermostatic Shower Set - 18" Shower Arm & Hand Shower - 1/2" IPS - Brushed Nickel, , large image number 0
Click to Zoom
Oxford Thermostatic Shower Set - 18" Shower Arm & Hand Shower - 1/2" IPS - Brushed Nickel, , large image number 1
Click to Zoom
Oxford Thermostatic Shower Set - 18" Shower Arm & Hand Shower - 1/2" IPS - Brushed Nickel, , large image number 2
Click to Zoom
Oxford Thermostatic Shower Set - 18" Shower Arm & Hand Shower - 1/2" IPS - Brushed Nickel, , large image number 3
Click to Zoom

Oxford Thermostatic Shower Set - 18" Shower Arm & Hand Shower - 1/2" IPS - Brushed Nickel

198345 SH198345
3.9 out of 5 Customer Rating
Select an Option
Brushed Nickel Select an Option
Brushed Nickel Select an Option

As Selected

$1,14900
Free Shipping
Details
You’ve reached the maximum quantity available

Shop In-Stock Selections

Estimate your Delivery Date
Relax and enjoy your shower with this premier temperature and pressure-controlled exposed pipe shower. Water cascades from a luxurious rainfall showerhead, supported by a graceful 18" arching shower arm. This two-piece riser unit allows for application as an extended height shower. The straight riser section is adjustable by cutting.
  • Thermostatic and pressure balanced. Keeps shower temperature ± 1 degree Celsius.
  • Equipped with backflow prevention.
  • Large 10" diameter rainfall shower head.
  • Heavy duty 1/2" IPS connections.
  • Two-piece exposed 78" riser pipe includes: 36" straight bottom riser, 42" arched upper riser (bottom riser is adjustable by cutting).
  • 12" long wall brace with flange.
  • Includes hand shower with porcelain handle, 60" spiral type hose, and wall mount cradle.
  • Two 1-3/4" wall mount couplers and decorative slip joint coupler included.
  • Faucet has 7" centers.
  • IAPMO listed/UPC certified.
Features
Product Type Shower Systems & Faucets
Design Traditional
Features Hand Shower Included, Pressure-Balanced, Thermostatic
Product Finish Brushed Nickel
Handle Material Metal
Handle Type Lever
Hand Shower Flow Rate 1.8 gpm (6.8 L/min) @ 80 psi
Material Brass
Number of Shower Heads 1
Rainfall Shower Head Flow Rate 1.6 gpm (6.0 L/min) @ 80 psi
Shower Head Flow Rate 1.6 gpm (6.0 L/min) @ 80 psi
Shower Head Installation Type Wall Mount
Shower Head Spray Rainfall
Shower Head Swivel Yes
Weight (lbs) 21.68
Dimensions
Hand Shower Hose Length 60"
Shower Head Diameter 10"
Shower Head IPS 1/2"
Resources
Specifications Installation Instructions
